- Pump and compressor automation
- Boiler systems
- Pressure alarm systems
- Industrial control panels
- Process safety systems
- Adjustable electrical contacts
- Magnetic Snap Action contacts
- Visual and electrical output combined
- Reliable switching mechanism
- Suitable for automation systems
- Compact and robust design
- Dial Sizes: 100, 150 mm
- Contact Type: Magnetic / Micro-switch
- Output: 1NO+1NC (2SPST) / others available
- Voltage Rating: up to 230V AC, 100mA max load (higher load available)
- Mounting: Bottom / Surface / Back / Panel / Clamp
- Gauge Accuracy: ±1% FSD
- Switching Accuracy: ±2% FSD
- Dual or multiple contact points : 1NO, 1NC, 1NO+1NC, 1NC+1NO, 2NO, 2NC,
also available 1SPDT or 2SPDT - Glycerin or Silicone oil-filled case for vibration damping
- Higher contact ratings : 220VDC, 5A or 230VAC, 5A (or 10A)
- Custom dial
