- Magnetic coupling eliminates leakage between pressure chambers
- Piston-based sensing for stable and accurate readings
- No direct contact between process fluid and indicator mechanism
- Suitable for higher pressure differentials
- Robust construction for harsh environments
- Low maintenance and long service life
- Ideal for filters
- Dial Size: 63 mm, 100 mm, 150 mm
- Measuring Element: Magnetic Piston with Spring
- Connection: Dual Pressure Ports (High & Low)
- Mounting: Direct / Panel / Surface Mount
- Accuracy: ±2% to ±3% FSD
- Wetted Parts: SS316 / Aluminium (as per application)
- Case: Stainless Steel / Engineering Polyme
- Differential Pressure Range: From low ranges (~0.25 bar) up to 30 bar or higher
- Maximum Static Pressure: Up to 100 bar to 400 bar (or higher depending on model)
- Filter and strainer monitoring
- Hydraulic and pneumatic systems
- Pump and compressor performance
- Heat exchangers and chillers
- Flow indication in pipelines
- Oil & gas and chemical industries
• Glycerine Filled
• Reed Switch / Electrical Contacts (for alarm/control)
• Different Process Connections (BSP / NPT)
• Panel Mounting / Surface Mounting
• Custom Differential Pressure Ranges
• Material Options for Wetted Parts
• Calibration / Test Certificates
