- Chemical and Petrochemical Industries
- Oil & Gas Applications
- Pharmaceutical Manufacturing
- Food and Beverage Processing
- Water Treatment Plants
- Hydraulic and Pneumatic Systems
- Power Plants and Boilers
- Marine and Offshore Applications
• SS304 case and ring (SS316 optional)
• High ingress protection (IP65/IP67)
• External zero adjustment (optional)
• Multiple mounting configurations
• Corrosion resistant construction
• Stable and accurate readings
• Long service life
• Case & Ring: SS304 Stainless Steel
• Wetted Parts: SS316
• Protection: IP65 / IP67
• Dial Sizes: 40, 50, 63, 100, 150, 200, 250 mm
• Mounting: Bottom / Back / Panel / Clamp
• Connection: BSP / NPT
• Ranges : 0 to 1 upto 2200 bar & -1 to 0 Vacuum & Compound
• Accuracy: ±1.0% / ±1.6% FSD
• SS316 case & ring
• Glycerin / Silicone filling
• Custom dial / pressure scale
• Electrical contacts
• 4–20 mA output
• Oxygen cleaning
• Maximum Pointer
• NABL Lab Calibration Certificate
